FOCUS PRO

Forensic Light Source

The FOCUS PRO, engineered from the original FOCUS LED, refining what worked and innovating from there to offer a superior hand-held LED. Beginning with the optics, the FOCUS PRO’s illumination is uniform and void of photography complicating hot spots. The homogeneous spot with defined edges provides the consistent intensity necessary to properly capture photos where there are no under/over developed sections in the same image.

New Features

Increased intensity
Waterproof

Segment: Scientific

Division: Forensics

Manufacturing Company: HORIBA Scientific

Compact Design
Uniform Illumination
IPX7 Waterproof
Ruggedized
IR

Intensity

The FOCUS PRO is the brightest in its class and fits in the palm of your hand. Its ultra-compact size is perfect for up close examinations. The superior optical design ehind the FOCUS PRO maximizes beam projection. No other LED on the market can offer such a compact unit and produce the same results.

Decontamination

Cleaning and decontaminating is easy with the IPX7 waterproof rated FOCUS PRO. Submerge with confidence in between crime scenes or victims to assist in rapid leaning to avoid cross-contamination. If there is evidence in a scene requiring a HAZMAT suit, the FOCUS PRO is the tool for the job.

You can detect these and more:

Biological Fluids, Bruises, Trace Evidence, Hair, Fingernails, Bones, Teeth, Bite Marks, Drugs, Footwear Impressions, GSR, Explosive Residues, Treated Fingerprints

Components and Specifications:

Rugged, portable, waterproof IPX7 LED with one click activation
Weatherproof IP67 carry case
4 pairs of goggles: 1 UV protection, 1 Yellow, 1 Orange, 1 Red
62 mm camera filters and viewing shields
Batteries and chargers

System is manufactured under ISO 9001-2015 standards.

Type of Source: LED – Light Emitting Diode
Life Time: 20,000 hours
DC Electrical Specifications: Rechargeable Li-ion Batteies and Chargers
Warranty: One Year on Parts and Labor

FOCUS-PRO-7F Includes the following wavelengths:

UV365 nm, UV395 nm, 470 nm, 530 nm, 625 nm, IR850 nm, White

FOCUS-PRO-3F

Also available (user choice of wavelengths)

On some individuals, a tunable or multiple wavelength forensic light source may reveal bruise and patterned wound details that are invisible under normal white light illumination.

Detection of Body Fluids with an Alternate Light Source

Since body fluids like semen, saliva, and vaginal fluids are naturally fluorescent, the use of a light source offers a unique method for locating them. A crime scene investigator can narrow down the specific locations of stains for collection instead of testing entire, large pieces of evidence such as a mattress, a carpet, a sheet, an article of clothing, etc. The dried body fluids will actually glow under the light source illumination.
