• Real-time monitoring
  Fast response and excellent repeatability allow real time tracking of changes in vapor concentration
• Multi-calibration Curve Function (Optional)
  Allows for concentration measurement of up to 3 chemicals or ranges
• Multi-display Function
  The multi-display function on the top of the IR-300 unit gives the user onsite checking capability of concentration monitoring and precursor supply line status
• Communications Function
  Connectivity through DeviceNet™, RS485 and analog communications
• Simple, Compact Design
  With a face-to-face size of 124 mm, the unit’s compact and mount-orientation-free design allows for easy integration

A high optical intensity and long-life light source combined with high-speed signal processing enables the IR-300 Series to achieve faster, more repeatable responses to changes in precursor concentration. These features give the user a true understanding of the actual process though real-time inline concentration measurement.

Measurement Example of MOCVD Precursor

■Experiment flow sheet

■Monitoring of precursor concentration change

Here is an example in which the concentration of the supplied precursor—which changes due to adjustment of the pressure in the bubbler by the back pressure regulator—was monitored in real time.

Measurement Techniques

Reliable, High-performance
Non-dispersive Infrared Absorptiometry (NDIR)

The infrared absorptiometry method employed by the IR-300 Series uses the principle of measuring the absorption of gas molecules in infrared light emitted from an infrared light source. A sample output from a sample that has absorbed the gas being measured is compared to a reference output with no absorbance, and the result is converted into a gas concentration. The use of this double beam method enables long-term, stable measurement results to be obtained.

The optical system is made up of a light source, gas cell and double beam detectors. The stability of the double beam detector has been proven over a period of more than 40 years.
