Spectrometers - CP140 - Imaging Spectrograph

The CP-140 Imaging Spectrograph offers the OEM customer a sturdy, low-cost, f/2, modular instrument, with unsurpassed spatial resolution. High-efficiency, ion-etched, holographic gratings make the CP-140 the perfect spectrograph for use with multiple fiber inputs, linear arrays, and CCD type detectors. Selected gratings cover specific spectral regions from 190 nm to 2500 nm.

See all our Imaging Spectrometers, for OEM industrial and research applications – Multitrack-MultiSpectra-Hyperspectral

Segment: Scientific

Division: Mini-Spectrometers and Scientific Cameras for OEMs

Manufacturing Company: HORIBA Scientific

Mutli-Channel Imaging Spectrometers

Multiple fiber input Imaging spectrographs allow you to monitor 5-10-20 and more INDEPENDENT fiber channels on a single spectrometer. The CP140 (5-6 simultaneous channels over 6 mm CCD height) or "OEM-CC-55 (8-20 and more non simultaneous channels) can be configured with multiple fibers on the entrance port (single column of fibers for simultaneous acquisition or more columns for non simultaneous acquisitions).
Minimized cross-talk, very low stray-light and a selection of low cost or high sensitivity CCD detectors. No plan to use fibers, need direct imaging? Please discuss your entrance optics needs for the CP140 or the OEM-CC-55 Hyperspectral imaging spectrometer with direct line imaging without fiber bundles.

If interested in high spectral resolution together with imaging performance, please contact us about the Research spectrometers: iHR320 (320mm focal length) and iHR550 (550mm focal length) perform multi-track experiments with up to 20+ fiber inputs.

Model	Grating Ref Number	Grooves per mm	Wavelength Range (nm)	Length of Spectrum (mm)	Average Dispersion (nm/mm)
CP 140 - 103	533 02 100*	285	190 -800, B 250	25.2	24.2
CP 140 - 104	533 02 090*	285	250 - 850, B 350	24.7	24.3
CP 140 - 202	523 02 190	140	190 - 800	12.2	50
CP 140 - 1602	533 02 040*	405	285 - 715, B 350	25.6	16.8
CP 140 - 1603	533 02 030*	405	190 - 410, B 250	12.8	17.2
CP 140 - 1604	533 02 030*	405	190 - 625, B 250	25.6	17
CP 140 - 1605	533 02 050*	405	380 - 780, B 450	24	16.7
CP 140 - 1821	523 02 110	230	700 - 1700	34.9	28.6
CP 140 - 1824	523 02 120	230	400 - 1100	23.3	30
CP 140 - 1825	523 02 120	230	380 - 780	13.2	30.3
CP 140 - 2021	523 02 210	120	1100 - 2500	24.7	56.6
CP 140 - 2951	523 02 250	97	800 -1700	12.7	70.
